ZEISS CONQUEST V4 1-4X24 RIFLE SCOPE

ZEISS

< Back

zeiss 11

zeiss 22

zeiss 33

 Click the image to enlarge


PERFORMANCE

Magnification

1-4 X

Effective Lens Diameter

12.1 - 24 mm

Light Transmission

90%

Exit Pupil Diameter

11.9 - 6 mm

Twilight Factor

3.5 - 9.8

Field of view at 100 m (yds)

38 – 9.5 m (114 – 29 ft)

Objective viewing angle

21.5° – 5.4°

Diopter adjustment range

+ 2.0 | − 3.0 dpt

Eye relief

90 mm (3.54 ")

Parallax setting

91.4 m (100 yds)

Adjustment range at 100 m

300 cm

Adjustment per click at 100 m

1.4 cm

Centre tube diameter

30 mm

Eyepiece tube diameter

44 mm

Objective tube diameter

30 mm


FEATURES

LotuTec | Nitrogen Filled

+ | +

Water Resistance

400 mbar


PHYSICAL

Operating Temperature

− 25°C | + 50°C (− 13°F | + 122°F)

Length

256 mm (10.1 ")

Weight (without inner rail)

470 g (16.6 oz)

Weight (with inner rail)

-

PRODUCT DETAILS

The Conquest V4 line of high-performance riflescopes combines the tried-and-true ZEISS optics concept with a rugged and functional design. Their compact design and perfect balance between a wide field of view and large magnification range is ideal for all types of hunting. The V4 models are equipped with a 4x zoom and functional, high-precision, and fully reliable mechanical components.

Special models have a ballistic turret with a wide reticle adjustment range (elevation and windage). As a result, the hunter has the flexibility needed for a variety of different hunting methods.  Optional ballistic reticles are also available that allow the hunter to quickly make elevation and azimuth corrections with no mechanical adjustment necessary.

The ZEISS Conquest V4 1-4x24 has proven to be the perfect riflescope for short-range hunting and situations which require the hunter to rapidly acquire the target. The up to 4x magnification is a clear advantage over simple red dot sights.

Main Use:

- Driven Hunt
- Stalking
- High Seat/ Night
- Medium Range / Alpine Hinting
- Long Range

Features:

4 x Zoom Range

The 4x zoom range allows hunters to perfectly recognize details and offers an excellent overall view for a safe and accurate shot.

A clear view, whatever the weather

There are always exciting things to be seen in the world of nature – even in wet weather. This is why ZEISS developed LotuTec®. A coating for the lenses of binoculars and spotting scopes that enables a clear and unhindered view in all weather conditions.

Stable and Shot-Proof

The ZEISS V8, ZEISS Victory HT, ZEISS Conquest V6, and ZEISS Conquest V4 riflescopes are all ideally suited for use with "clip-on" attachments.

90% Light Transmission

Higher definition glass produces 90% to-the-eye light transmission, great low-light performance and excellent target resolution across the entire magnification range.

ZEISS T* Coating

ZEISS T* coating is a guarantee of the brilliant, high-contrast images­­ which you will experience above all in adverse light conditions and in the twilight. Behind it, however, there is no specific formula for building up the layers. Instead, it is a technology that is constantly adjusted to suit new glass materials and requirements, which varies from lens to lens.

Reticle Illumination

The reticle illumination can be adjusted finely and accurately over 10 different levels, allowing hunters to precisely adjust the brightness to any situation and time of day – for the perfect shot.


reticle

Reticle 60

Illuminated

The reticle 60 is lighter and finer than the reticle 40, which was widely used only a few years ago. The bars have only half the subtension of the earlier model and there is twice the amount of free space between them. It is therefore ideally suited for precise shooting with the least possible coverage of the target game. With 12x magnification and a subtension of only 0.55 cm at a distance of 100 m, you always have an excellent overview – no fine details are hidden from view. The illuminated dot is extremely bright and can therefore also be used for daytime hunting. The brightness of the illuminated dot can be dimmed at extremely finely, making it ideal for night hunting as well. The reticle is located in the riflescope’s second image plane.
