Mount-Type

Ring-mount, Rail-mount

Reticle

4A-I

Objective

1-8x
Magnification

8.2-24 mm
Effective objective lens diameter

8.1-3.0 mm
Exit pupil diameter

95 mm
Exit pupil distance

42.5-5.3 m/100m
Field of view

24.0-3.0 °
Field of view degrees

24 °
Field of view apparent

-3 to +2 dpt
Diopter adjustment

93 %
Light transmission

2.8-13.9
Twilight factor acc. to ISO 14132-1

Measurement

0.36 / 10
Impact point correction per click (in / mm)

2 / 72
Max. elevation / windage adjustment range (m/100m / in/100yds)

Digital

M 27x0.75
Objective filter thread

Twilight factor at medium brightness: 1,400; daylight factor at medium brightness: 180
Operating time

Size & Weight

301 mm
Length in mm.

515 g
535 g
Weight

30 mm
Central tube diameter

Environment & Conditions

-20 to +55 °C
Functional temperature

-30 to +70 °C
Storage temperature

13 ft / 4 m water depth (inert gas filling)
Submersion tightness

Illumination

Twilight: 0 - 32 / Day: 33 - 64
Brightness levels
